Technical parameters:
|
Model
|
WS-P2060
|
|
Working size
|
2000x6000mm
|
|
Gas
|
Compressed air
|
|
Usage
|
Metal fabrications
|
|
Repeat positioning accuracy
|
±0.05mm
|
|
Process precision
|
±0.35mm
|
|
Transmission system
|
Taiwan Hiwin Square guide rail
|
|
Rack pinion with X Y and ball screw with Z
|
|
Max. cutting speed
|
12000mm/min
|
|
Working voltage
|
AC380 /220V 3PH 50 /60HZ
|
|
Control system
|
Starfire control system
|
|
THC
|
Torch Height Controller
Standard high sensitivity arc voltage device
|
|
Oil lubrication
|
Automatic
|
|
Instruction format
|
G code
|
|
Drive system
|
Stepper motor and drivers
|
|
Relay accessories
|
Schneider
|
|
Nesting Software
|
FASTCAM
|
|
File output mode
|
USB interface
|
|
Plasma source
|
Maxpro200
|
|
Packaging size
|
683x227x158cm
|
|
G.Weight
|
2000kgs
|
Machine details and features:
1. Welded steel tube structure
2. Machine table
Saw-shape machine table holds metal sheet steady with little touch with metal sheet. The saws are thick and durable. In front and both sides of machine table, there are rolling balls for assisting sheets loading.
Machine table size is 2000mm by 6000mm.
3. Drawer under table to collect small cutting pieces.
4. Starfire control system
Advanced technology, suitable for all kinds of flame / plasma, widely used in metal processing.
Practical flame/plasma cutting process, automatic corner rotation control and height control control during plasma processing; remote operation with wireless remote control.
It has the function of kerf compensation, and whether the compensation in the program is reasonable, and the corresponding report is made for the user to choose;
Breakpoint recovery, automatic power-off recovery function, automatic memory breakpoints;
Fully compatible with StarCAM / FASTCAM and other nesting software;
Support multi languages, dynamic graphic display, 7-inch color LCD display; U disk reading program
5. Transmission System
Machine is with helical rack pinions and Hiwin linear guide rails, which ensures machine high speed movement, precision and stability as well. The transmission system is protected by dust shields.
6. Driving System
Adopt dual motor driving. Ensure good running stability.
7. Plasma source: Maxpro200
This 200A US hypertherm plasma cutting machine is an updated model based on MAXPRO200.
8. Torch height controller
it will detect the voltage changes, then control the distance between cutting torch and work piece via the lifting motor in order to keep the arc voltage within a given range, so that the height of cutting torch is kept within a corresponding range.
9. Oil lubrication system
It automatically lubricates guide rails, which ensures the machine keep moving smoothly and with good precision.
10. Fastcam Nesting Software
It has been designed to draw, nest and cut metal as simply and efficiently as possible.
